Laser Cutting Machine Grbl 32Bit Pwm Control Laser Engraving Machine (No Laser)

Motherboard:32 bitsmotherboard with 32 Bits MCU Firmware:GRBL1.1 OS of Upper Computer: Windows ( Working with LaserGRBL ), MAC OS and Linux /Phone(Bring yourown software) Power Supply:12V 5A60W USB Interface：Type C Electrical Power ：80W Actual Power:10W Wavelength:450nm Input Format: NC, BMP, JPG, PNG, DXF, etc. Carving Area:X: 400MM x Y: 400MM Image size: No Limit ( The pixel accuracy could be adjusted freely, and the default is 300 pixels per inch, its about 0.81um pixel precision ) Tip:The gantry structure does not need to be assembled. The others are all parts and need to be assembled by yourself. We provide instructions and video tutorials. Please feel free to contact us if you have any questions.

【Motherboard with 32Bits MCU】 It could preprocess 32 instructions, support baud rate as high as 921600,, more powerful! 【The Most Advanced 32Bits Laser Engraver Firmware】 GRBL 1.1 laser master firmware, smarter, faster, higher precision and easier to use. 【Laser power range could be S0 - S1000】 Laser Master could control laser beam more accurately, could even use the high power laser unit to "draw" a picture on paper , that the 8bits high power laser engravers could not do. 【Engraving speed could be as high as 3000MM/Min】 If do not consider the laser carving result, the velocity of movement could be as high as 1000MM/S LightBurn(paid software, lightburnsoftware.com) supports Windows, Mac OS, and Linux. Its the most popular paid carving software in the world, very easy to use.LaserGRBL for engraving and cutting.LaserGRBL( free software ) supports Windows XP, 7, 8, 10.

LaserGRBLis the most popular carving software in the world, could import different format images, you could editing in PhotoShop, Inkscape, CAD, etc. And then connect to the engraver via laser Packing List: Friendly Reminder: Please wear goggles when operating the laser engraver. Wear safety goggles to avoid blindness. Please do not touch the laser emitter with your hand, or it may burn your hand. Please avoid strong impact on the machine.Children under 14 are not allowed to use this product and children over 14 need adult supervision.

The light engraving machine can not be directly applied to any mirror reflecting object, which may cause injury to the operator or burn the laser. This product is not recommended for industrial cutting due to its high engraving speed.
