Material: Metal
Type: Engraving
Laser Power: 30W
Laser Wavelength: 1.064μm
Laser Pulse Repetition Rate: 20k - 60K Hz
Positioning Accuracy: 0.01mm
Minimum Line Width: 0.01mm
Marking Area (mm): 200X200mm
Marking Speed: 0-8000mm/s
Minimum Character Size: 0.2mm
Single Marking Depth: 0.005mm – 1mm
Best Distance between Laser Lens and Material Surface: 260mm
Vertical Stroke of Lifter: 50cm
Working Life of Laser Generator: 100000 hours
Cooling Method: Air
System Voltage: 220V 50Hz
System Power: 400W
Interface Port: USB 2.0
Working Temperature: 5-35 ℃
Working Relative Humidity: 5-85%
Software: EZCADLaser Marking Software (included in the package)
Software Compatible OS: Windows7, Windows8, Windows10
Compatible Image Formats: BMP, JPG, TGA, AI, DXF, PTL, PNG, TIF, DX
Certification: CE, FDA
